散熱風扇 JHX12038
12038 尺寸/Size 120X120X38mm DC Axial Flow Fan
★Dimensions Drawing(外觀圖） ★Characteristic Curves(特性曲線)
|
★Specifications（規(guī)格） |
|||||||||
|
Model
型號 |
Bearing System 培林 |
Rated Voltage 電壓（V) |
Operation Voltage 電壓范圍 |
Current
電流（A) |
Input Power 功率（W) |
Speed 轉(zhuǎn)速 （RPM) |
Air Flow 風量 （CFM） |
Static Pressure 靜壓（mm-H2O) |
Noise Level 噪音（dB-A） |
|
JHX12038X12H |
Sleeve Ball |
12 |
10.8~13.2 |
0.60 |
7.20 |
3000 |
119.49 |
7.81 |
44.47 |
|
JHX12038X12M |
0.45 |
5.40 |
2700 |
107.54 |
6.66 |
41.51 |
|||
|
JHX12038X12L |
0.30 |
3.60 |
2400 |
79.66 |
5.26 |
39.98 |
|||
|
JHX12038X24H |
Sleeve Ball |
24 |
21.6～26.4 |
0.40 |
9.60 |
3000 |
119.49 |
7.81 |
44.47 |
|
JHX12038X24M |
0.30 |
7.20 |
2700 |
107.54 |
6.66 |
41.51 |
|||
|
JHX12038X24L |
0.20 |
4.80 |
2400 |
79.66 |
5.26 |
39.98 |
|||
