散熱風扇 JHX8038增壓
8038 尺寸/Size 80X80X38mm DC Axial Flow Fan
★Dimensions Drawing(外觀圖） ★Characteristic Curves(特性曲線)
|
★Specifications（規格） |
|||||||||
|
Model
型號 |
Bearing System 培林 |
Rated Voltage 電壓（V) |
Operation Voltage 電壓范圍 |
Current
電流（A) |
Input Power 功率（W) |
Speed 轉速 （RPM) |
Air Flow 風量 （CFM） |
Static Pressure 靜壓（mm-H2O) |
Noise Level 噪音（dB-A） |
|
JHX8038X12H |
Sleeve Ball |
12 |
10.8~13.2 |
0.70 |
8.40 |
5000 |
68.81 |
15.35 |
49 |
|
JHX8038X12M |
0.40 |
4.80 |
4300 |
57.31 |
10.87 |
45 |
|||
|
JHX8038X12L |
0.23 |
2.76 |
3400 |
45.20 |
7.13 |
39 |
|||
|
JHX8038X24H |
Sleeve Ball |
24 |
15～27 |
0.35 |
8.40 |
5000 |
68.81 |
15.35 |
49 |
|
JHX8038X24M |
0.23 |
5.52 |
4300 |
57.31 |
10.87 |
45 |
|||
|
JHX8038X24L |
0.12 |
2.88 |
3400 |
45.20 |
7.13 |
39 |
|||
|
JHX8038X48H |
Sleeve Ball |
48 |
35～55 |
0.20 |
9.60 |
5000 |
68.81 |
15.35 |
49 |
|
JHX8038X48M |
0.15 |
7.20 |
4300 |
57.31 |
10.87 |
45 |
|||
|
JHX8038X48L |
0.08 |
3.84 |
3400 |
45.20 |
7.13 |
39 |
|||
